50.000 can/h Isobaric Filler and Seamer - fully rebuilt

Category: Isobaric Filling / Seaming System

Make: CROWN / ANGELUS

Year: 1995

High-Performance Filling Line for Carbonated Beverages and Beer This complete isobaric can filling and seaming unit combines the renowned precision of CROWN filling technology with the reliability of an ANGELUS 120L seamer. Designed for high-speed beverage production up to 50,000 cans per hour, it ensures exceptional filling accuracy, hygienic operation, and consistent product quality. ⚙️ Technical Overview Manufacturer (Filler): CROWN Manufacturer (Seamer): ANGELUS Model: 72V Filler + 120L Seamer Type: Isobaric filler with 72 valves Capacity: 50,000 cans/hour (330 ml aluminum cans) Product types: Carbonated soft drinks, beer CO₂ level: Up to 8 g/l Filling temperature: 4–8 °C Can format: 330 ml (Ø 66.7 mm body) Lid type: 202 Pitch: 103.67 mm Compressed air requirement: 15 m³/h at 6 bar Electrical supply: 3 x 400 V, 60 Hz Control voltage: 24 V DC Power consumption: 20 kW Noise level: ≤ 78 dB(A) Protection class: IP 54 Approximate weight: 10,000 kg 🧩 Filler Features CROWN 72V - Rebuilt Stainless steel AISI 316L filling valves, fixed to the bowl for high precision 72 isobaric filling valves – accurate and consistent filling performance Mechanical can lifters (no pneumatic lifters) No can – no fill safety device Adjustable filler bowl height for different can sizes CO₂ purging from the bowl to minimize oxygen pick-up CIP closed system with integrated cleaning caps Centralized lubrication system for reduced maintenance Infeed screw and product level control system Fully stainless steel AISI 304 frame with polycarbonate safety enclosure Siemens S7 PLC with touchscreen and frequency inverter 🧰 Seamer Features ANGELUS 120L – Rebuilt 12-head rotary can seaming turret for high-speed sealing Constructed from carbon steel and AISI 304 stainless steel Double cam system for precision lid control Automatic lid feeder with one-screw unstacker and lid presence sensor CO₂ gassing system under cover for improved product stability No can – no lid electronic safeguard Driven can lifters with precise control Manual centralized lubrication system Full stainless steel safety closure and transfer table between filler and seamer Suitable for one can format (330 ml / Ø 66.7 mm body / 202 lid) 💡 Key Advantages ✅ High output – up to 50,000 cans/hour ✅ Designed for beer and CSD production ✅ Hygienic stainless-steel design – easy to clean and maintain ✅ CO₂ purging ensures extended product shelf life ✅ Reliable performance from two of the industry’s top brands: CROWN & ANGELUS ✅ Ready for integration into a complete canning line 📦 Scope of Supply Filler–Seamer block with common AISI 304 frame Electrical cabinet with Siemens PLC control Frequency inverter and touchscreen HMI Transfer table and conveyor for filled cans Safety enclosure and lubrication system Documentation and operation manual available
